Vinyl Sheet Piling: Z type

product description

Vinyl Sheet Piling: Z type

Sheet piling is commonly used in projects designed to stabilize and raise the height of levees and earthen dams. Vinyl sheet piling can help to prevent overtopping, internal seepage, piping of stratum, surface erosion and rodent damage. Leading project engineers, government agencies and general contractors all over the world choose to design with and install synthetic sheet piling for a long list of water control applications from demanding projects involving harsh acid mine drainage to simple erosion control or water diversion operations. Vinyl sheet piling systems are the new standard with many advantages compared to hard wood, concrete and steel sheet piling. Vinyl sheet piles are made of poly vinyl chloride also known as PVC a material with excellent resistance to weather influences and it has a long service life.

Vinyl PVC Sheet Piling Parameters

MaterialPVC
Section Width457 mm
Section depth254 mm
LengthCustomization
Thickness11.18  mm
PackageCustomization
ColorGrey/customization
Weight11.5±1 kg/m
Moment of inertia22709 cm4/m
Section modulus1717 cm3/m
Ultimate moment7948 kg-m/m
Tensile Strength44.8 Mpa
Flexural Strength78 Mpa
Modulus of Elasticity2620 Mpa
Notched Izod impact2.46 Kg/cm
Heat Deflection Temperature70℃
